Hanwha Vision
Wisenet XND-8020F 5 Megapixel Indoor Network Camera - Color - Dome - Black, Ivory - MJPEG, H.264 (MPEG-4 Part 10/AVC), H.265 - 2560 x 1920 - 3.70 mm Fixed Lens - 30 fps - CMOS - Flush Mount
Part number XND-8020F
Wisenet XND-8020F 5 Megapixel Indoor Network Camera - Color - Dome - Black, Ivory
NDAA Section 889 / TAA-compliant — country of origin confirmed on quote
We confirm stock, country of origin and compliance before any order — no payment up front.
Highlights
- 5MP @ 30fps
- Triple codec H.265/H.264/MJPEG
- 3.7mm fixed lens
- Wide dynamic range 120dB
- On-board analytics (business/audio and video)
- Digital image stabilization
Tech specs
Specifications
| Product Type | Network Camera |
| Maximum Aperture | f/1.6 |
| Maximum Video Resolution | 2560 x 1920 |
| Maximum Frame Rate | 30 fps fps |
| Maximum Focal Length | 3.70 mm mm |
| Image Sensor Type | CMOS |
| Effective Camera Resolution | 5 Megapixel Pixel |
| Field of View | H: 97.5°/ V : 71.9°/D: 126.2° |
| Minimum Operating Temperature | 14°F (-10°C) °F |
| Maximum Operating Temperature | 131°F (55°C) °F |
| Network (RJ-45) | Yes |
| Longest Shutter Speed | 2 Second |
| Shortest Shutter Speed | 1/12000 Second |
| Lens Mount Type | Board Mount |
| Remote Management | Yes |
| HD Recording | Yes |
| Lens Included | Yes |
| Storage Type | Memory Card |
| Indoor/Outdoor | Indoor |
| Product Color | Black |
| Product Color | Ivory |
| Color Family | Dual Color |
| Maximum Operating Humidity | 90% % |
| Diameter | 3.9" mm |
| Height | 5.1" mm |
| Color Supported | Color |
| Connectivity Technology | Wired |
| Product Series | X |
| Features | Audio Detection |
| Features | Auto Gain Control |
| Features | SD Card Local Storage |
| Features | Day/Night |
| Features | Back Light Compensation (BLC) |
| Features | Highlight Compensation (HLC) |
| Features | Wide Dynamic Range |
| Features | 3D Digital Noise Reduction |
| Features | 2D Digital Noise Reduction (2DNR) |
| Features | Digital Image Stabilization |
| Features | Privacy Masking |
| Features | Automatic White Balance |
